Page 123 - 45-3

วารสารราชบััณฑิิตยสภา
ปีีที่่� ๔๕ ฉบัับัที่่� ๓ กัันยายน-ธัันวาคม ๒๕๖๓

ศาสตราจารย์์กิิตติคุุณ ดร.สมศักิดิ� ดำารงเลิิศ แลิะคุณะ 115

เริ�มต�น ๑ บรรยากาศึ เวลา ๓๐ นาที สัามารถผู้ลิตอะคริโลไนทริลได�ร�อยละ ๑๔.๕๗ โดย
นำ�าห์นัก

คัำ�สำำ�คััญ : แอมมอกซิเดช้ัน โพรเพน โพรพิลีน อะคริโลไนทริล ตัวเร่งปฏิิกิริยาแบบห์ลาย
องค์ประกอบ

Abstract: Ammoxidation of propane on multicomponent catalyst
Professor Emeritus Dr. Somsak Damronglerd
Fellow of the Academy of Science,
The Royal Society of Thailand.
Professor Dr. Pramote Chaiyavech

Associate Fellow of the Academy of Science,
The Royal Society of Thailand.
Mr.Wiwat Yingsuttipan
Department of Chemical Technology, Faculty of Science,
Chulalongkorn University
The experiment was done to synthesize acrylonitrile from propane in a
75 ml. reactor. It was performed in two processes; there are two steps in the
first process and one step in the second process. In the first step of the first
type, propane was converted to propylene by using Pd/Activated carbon as a
o
catalyst with the optimum condition: temperature 420 C, initial pressure 1 atm.
and reaction time 30 minutes. In the second step, propylene was transformed

to acrylonitrile by using two types of catalysts, i.e., Cu/multicomponent bismuth
phosphate and Cu/Zeolite. So, in the second process which directly converts
propane to acrylonitrile. The experiment was operated with Cu/multicomponent
bismuth phosphate; it was found that the optimum conditions were temperature
o
400 C, pressure 1 atm. and reaction time 30 minutes. The acrylonitrile was formed
at about 31.27%. In case of Cu/Zeolite catalyst, it can produce acrylonitrile
at only 6.29% by weight. The reaction using Cu/multicomponent bismuth
phosphate can produce acrylonitrile five times higher than when using Cu/Zeolite.

Keywords: ammoxidation, propane, acrylonitrile, multicomponent catalyst
